Design & Functionality:
PHYSICAL
Size (W x H x D) mm – Main (w/o foot ) mm 890x55x85Size (W x H x D) mm – Main (w/ foot ) mm Matching TV size (’17 New Designed LG TV) 40 inch ↑
Size (W x H x D mm) -Main (w/o foot ) mm (Built-in Foot (H) mm) 2Size (W x H x D) mm – Wireless Box 60x220x175
Size (W x H x D) mm – Rear Speaker 88x122x81Size (W x H x D) mm – Subwoofer 171x320x252
Material – Mainset (Front) MoldMaterial – Mainset (Top / Bottom) Mold
Material – Wireless Box – Front MoldMaterial – Wireless Box – Top / Bottom Mold
Material – Rear speaker – Front MetalMaterial – Rear speaker – Top / Bottom Mold
Material – Subwoofer (Front) JerseyMaterial – Subwoofer (Body) Wood
Net Weight (Kg) – Main 2.4KgNet Weight (Kg) – Wireless Box 0.97Kg
Net Weight (Kg) – Rear Speaker 0.87KgNet Weight (Kg) – Subwoofer 4.2Kg
Carton Size (W x H x D) mm 946x373x223Carton Type Offset
Gross Weight (Kg) 11.4KgContainer Q’ty – 20ft 359
Container Q’ty – 40ft 753Container Q’ty – 40ft (HC) 867
CHANNEL/OUTPUT POWER
Channel 4.1chOutput Power (THD 10%) – Total 420W
Output Power (THD 10%) – Front 60Wx2 (Tweeterx2)Output Power (THD 10%) – Surround 60Wx2
Output Power (THD 10%) – Subwoofer 180W(Wireless)
SPEAKER
Main – SPL 82dBMain – System 2Way/Bi-Amping
Main – Tweeter Unit – Front Only 20mm PPS DomeMain – Woofer Unit 40x100mm/4ohm
Main – Impedance 4 ohmRear – SPL 82dB
Rear – System Closed TypeRear – Woofer Unit 2.5 inch paper (BK)
Rear – Impedance 3 ohmSubwoofer – SPL 85dB
Subwoofer – System Bass ReflexSubwoofer – Woofer Unit 6 inch
Subwoofer – Impedance 3 ohm
CONNECTIVITY
General – Audio Input (Portable In (3.5Ø)) YesGeneral – Optical Yes(1)
General – HDMI 1.4 (HDCP 1.4) (In / Out) Yes(1) / Yes(1)General – USB Yes
Wireless – Bluetooth (ver. 4.0) Yes
INFORMATION DISPLAY
Display Type Dot LEDLED indicator Color Red (Stand By) + White (5)
SOUND MODE
4K Sound-24bit/96kHz YesSound Effect – ASC (Adaptvie Sound Control : Default) Yes
Sound Effect – Standard YesSound Effect-Bass Blast Yes
Sound Effect – Cinema (Sound Field eXtension default) YesAuto Sound Engine – Default Yes
CONVENIENCE
Smart Phone App – Bluetooth (Android / iOS) Yes / NoSmart Phone App – Update manager Yes
Bluetooth Stand-By YesRange of Flow (BLE) Yes
Control with your TV Remote – Vol + , – , Mute YesSound Sync – Bluetooth (LG TV) Yes
Sound Sync – Optical YesAutomatic Power on/off – Bluetooth (LG TV) Yes/Yes
Automatic Power on/off – Optical Yes/YesSimplink Yes
Audio Return Channel (ARC) YesRear Speaker Level – – 6 ~ +6 (Step) Yes
Woofer Level – -15 ~ +6 (Step) YesMute Yes
USB Host YesWireless Rear Speaker – 1:1 Rx module Type (Wireless Kit for Rear) Yes
AUDIO FORMAT
LPCM YesDolby Digital Yes
DTS Digital Surround YesFLAC – Up to 192kHz Yes
OGG – Up to 48kHz YesWAV Yes
MP3 YesWMA Yes
POWER CONSUMPTION
Main – Type Adaptor (25V, 1.52A)Main – Power Off Consumption 0.5W Under
Main – Power Consumption 22WWireless Box – Type (SMPS) 100~240V, 50/60Hz
Wireless Box – Power Off Consumption 0.5W UnderWireless Box – Power Consumption 50W
Subwoofer – Type (SMPS) 100~240V, 50/60HzSubwoofer – Power Off Consumption 0.5W Under
Subwoofer – Power Consumption 33W
ACCESSORY KIT
Owners Manual – Web Yes (Full)Owners Manual – Book Yes (Simple)
Owners Manual – Wall Mount Guide YesOwners Manual – Wireless Speaker Reset Guide Yes
Owners Manual – 4K Sound YesOwners Manual – Open Source : X / Yes (Full / Simple) Yes (Full)
Remote Control Unit – Type MA5(Black)Remote Control Unit – Battery(Size) AAA x 2
Batteries YesWarranty Card Yes
Rear Speaker Cable YesOptical Cable Yes
Wall Mount Bracket YesBox Type Offset
